I’ve reviewed the the Octoml medium post by Thierry Moreau @thierry , which explains TVM and KWS (keyword spot) using Azure Sphere.
The code is in the below repo.
I am using the latest TVM
When I run the following code that export and quantize, I see an error in the quantization.
I have gone through the python functions and cpp functions in the the backtrace and print out the types (got the name_hint is list). It seems that during the quantization tvm::IRModuleNode::LookupTypeDef
failed to find the type def.
However, I am not sure how to debug the next.
Any help will be appreciated.
# described in https://github.com/octoml/azsphere/blob/master/README.md
$ python3 -m model.kws.kws --export --quantize --global-scale 4.0 -o build --debug
Error back trace
...
WARNING:root:Attribute T is ignored in relay.sym.softmax
WARNING:root:Attribute _output_shapes is ignored in relay.sym.softmax
WARNING:root:Attribute _node_name is ignored in relay.sym.softmax
WARNING:root:Attribute _target_layout is ignored in relay.sym.softmax
INFO: Quantizing...
INFO: Global Scale: 4.0
Traceback (most recent call last):
File "python3.7/runpy.py", line 193, in _run_module_as_main
"__main__", mod_spec)
File "python3.7/runpy.py", line 85, in _run_code
exec(code, run_globals)
File "Github/azsphere/python/model/kws/kws.py", line 327, in <module>
mod, params = export_module(OPTS)
File "Github/azsphere/python/model/kws/kws.py", line 120, in export_module
mod = relay.quantize.quantize(mod, params)
File "Github/tvm-upstream/python/tvm/relay/quantize/quantize.py", line 371, in quantize
mod = quantize_seq(mod)
File "Github/tvm-upstream/python/tvm/ir/transform.py", line 127, in __call__
return _ffi_transform_api.RunPass(self, mod)
File "Github/tvm-upstream/python/tvm/_ffi/_ctypes/packed_func.py", line 237, in __call__
raise get_last_ffi_error()
tvm._ffi.base.TVMError: Traceback (most recent call last):
[bt] (8) 9 libtvm.dylib 0x0000000112bb0770 tvm::NodeFunctor<void (tvm::runtime::ObjectRef const&, tvm::relay::ExprFunctor<void (tvm::RelayExpr const&)>*)>::operator()(tvm::runtime::ObjectRef const&, tvm::relay::ExprFunctor<void (tvm::RelayExpr const&)>*) const + 288
[bt] (7) 8 libtvm.dylib 0x0000000112e0b104 tvm::relay::ExprVisitor::VisitExpr_(tvm::relay::IfNode const*) + 52
[bt] (6) 7 libtvm.dylib 0x0000000112e05ac4 tvm::relay::MixedModeVisitor::VisitExpr(tvm::RelayExpr const&) + 1540
[bt] (5) 6 libtvm.dylib 0x0000000112e0543b tvm::relay::MixedModeVisitor::VisitLeaf(tvm::RelayExpr const&) + 59
[bt] (4) 5 libtvm.dylib 0x0000000112bb047d tvm::relay::ExprFunctor<void (tvm::RelayExpr const&)>::VisitExpr(tvm::RelayExpr const&) + 173
[bt] (3) 4 libtvm.dylib 0x0000000112bb0770 tvm::NodeFunctor<void (tvm::runtime::ObjectRef const&, tvm::relay::ExprFunctor<void (tvm::RelayExpr const&)>*)>::operator()(tvm::runtime::ObjectRef const&, tvm::relay::ExprFunctor<void (tvm::RelayExpr const&)>*) const + 288
[bt] (2) 3 libtvm.dylib 0x0000000112be2938 tvm::relay::TypeVarEVisitor::VisitExpr_(tvm::ConstructorNode const*) + 56
[bt] (1) 2 libtvm.dylib 0x0000000112347515 tvm::IRModuleNode::LookupTypeDef(tvm::GlobalTypeVar const&) const + 469
[bt] (0) 1 libtvm.dylib 0x0000000112116d6f dmlc::LogMessageFatal::~LogMessageFatal() + 111
File tvm-upstream/src/ir/module.cc", line 272
TVMError:
---------------------------------------------------------------
An internal invariant was violated during the execution of TVM.
Please read TVM's error reporting guidelines.
More details can be found here: https://discuss.tvm.ai/t/error-reporting/7793.
