[VTA] Workaround for Autotuning with One PYNQ Z1 Board

Development
#21

One way is to create a global class record cma alloc and free. When exception occurs, the python-rpc-server firstly provided the C API to invoke xilinx cma_free() to release the cma memory then terminate the process.

#22

Another way is to avoid rpc exception and improve tuning efficiency. I replace batch 300 input tensor with batch 1 input tensor. And use simple python script the generate simpler net. I thought that with GEMM batch 300 conv2d could share nearly the same optimal schedule with batch 1 conv2d.

#23

Hi @htt

Thank you for sharing your work. It seems the 2nd option made more sense, though it seems to be good to improve rpc exception handling.

Cheers, ISS

#24

Hi,

I want to check several things.

  1. Does your tutorial work with ‘xgb’ tuner?
  2. I tried to compare non-tuning with tuning and failed to see the improvement for execution time after tuning. Did you see the improvement after tuning?
  3. @isong I’m using one PYNQ-Z1 board. When I ran the tutorial, the mean inference time was 365 ~ 372 ms. Your example shows 69.65 ms. Could you give me some advice to decrease the mean inference time?

Thanks!

#25

@thkim

  1. I am not sure, but with random tunner it works.

  2. Because you use the tophub well-tuned params. If you try with fallback config, it will be great improvement.

  3. I use PYNQ Z1 and ZCU104. I think 365ms is reasonable.

1 Like
#26

Hi @thkim

For 1 and 2, I think @hht has already answered.

For 3, I used ultra96, could be the reason why the difference.

1 Like
#27

@hht

I have create a PR that combines your change and my change that is discussed in the thread. I wanted to add you to the PR, but I cannot seem to find you in @ at github id.

1 Like
#28

@isong

I see you already @ me. Hope this commit can pass.

#29

Recently, I encountered this problem again. Using a single pynq Z2 will prompt that the device cannot be obtained from remote. My TVM version is v0 8. Do you have any suggestions? Thank you.

#30

Have you solved the problem? I also encounter the problem, My TVM version is 0.9, and remote device is PYNQ Z2.

#31

@youxiudeshouyeren Do you have any ideas?

#32

@hht Hello, I meet the same problem now.
If you remove the remote , then how could you program the FPGA with bitstream?
And should I run start_rpc_server.sh or start_rpc_server_to_tracker.sh ? What’s the difference?
